High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install

چین High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install تامین کننده
High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install تامین کننده High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install تامین کننده High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install تامین کننده

تصویر بزرگ :  High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install

جزئیات محصول:

Place of Origin: Guangdong
نام تجاری: E-link
گواهی: CE FCC RoHS
Model Number: LNK-DF100 Series

پرداخت:

Minimum Order Quantity: 1
قیمت: USD79-99/pair
Packaging Details: Standard export package
Delivery Time: 5-8
Payment Terms: T/T
Supply Ability: 10000
Contact Now
توضیحات محصول جزئیات
Video Standards: DVI1.0; HDCP1.2 Video Connector: DVI-D
Audio Interface: 3.5mm earphone seat Audio Signal type: Stereo
Power dissipation: MAX 6W Temperature: Operating: -5℃ ~ +70℃

DVI over Fiber Optic Extender

Model: LNK-DF100 Series

Overview

The LNK-DF100 DVI Fiber optic extender provides extension of DVI signals long distances over one fiber optic cable, it supports high resolution up to 1080P, external audio transmission; function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.



Features

  • Transmits DVI video signals and audio up to 20km over a single fiber optic cable;
  • Support video resolution up to 1920*1080@60Hz ;
  • Support external stereo audio forward transmission;
  • Compliance with DVI 1.0 and HDCP 1.2 standard;;
  • High compatibility, can auto-match source and display device;
  • Built-in automatic adjustment system, make the image smooth, clear and stable;
  • Built-in ESD protection system;
  • Simple to install, plug and play;

Technical Indexes

Parameter Description
Video Standards DVI1.0; HDCP1.2
Maximum pixel clock 165MHz
Maximum data rate 6.75Gbps
Resolution range

1920x1080P 1280 x 720 1024 x 768

1280 x 1024 1440 x 900 1680 x 1050 800 x 600

Connector DVI-D
Impedance 100Ω
DVI Cable Range <5Meter (Resolution up to 1920*1080@60Hz)
Audio Interface 3.5mm earphone seat
Signal type Stereo
Optical fiber Interface SFP model – LC connector
Fiber type Single-mode
Wavelength 850nm/1310nm
Interface bandwidth 1.25Gbps
Transmission distance

Transmission@1920*1080@60Hz

OM3 Multi-mode fiber: <300M

Single-mode fiber: 20km

Other Power supply The power adapter: DC 5V~12V
Power dissipation MAX 6W
Temperature Operating: -5℃ ~ +70℃
Humidity Operating: 5% ~ 90%
Dimension (LxDxH) 63*93*25mm


Panel

Transmitter

High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install

Receiver

High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install

Port Name Description
INPUT/OUTPUT DVI Signal Input/Output
AUDIO IN/OUT External Stereo Audio Input/Output
DC5-12V Power Adapter Socket
OPTICAL SFP Module, LC Connector (T: Transmitter; R: Receiver)
LED Indicator Description
STATUS Video Signal Lock Indicator(ON: Lock; Off: Unlock)
POWER Power Indicator(ON: Power Input; Off: No Power Input)



Ordering Information

Item Description

LNK-DF100 DVI Fiber Optic Extender: 1920*1080P@60Hz, Compliance with DVI 1.0 & HDCP1.2 standard, Support external stereo audio forward transmission, LC(SFP), OM3 Multimode fiber, 300m, including 1 transmitter & 1 receiver, used by pairs
LNK-DF100S DVI Fiber Optic Extender: 1920*1080P@60Hz, Compliance with DVI 1.0 & HDCP1.2 standard, Support external stereo audio forward transmission, LC(SFP), single mode, single fiber, 20km, including 1 transmitter & 1 receiver, used by pairs



High Resolution DVI HDMI Over Fiber Optic Extender Plug And Play Simple To Install
